C 1214
“Loud and clear.”
C 1214 Specifications.
| Specifications | C 1214 unpowered |
| Frequency response | 120 - 19.000Hz ±3dB (50Hz @ -10dB) |
| F MOD / D MOD low cut modes | OFF / 70 / 100 / 120Hz |
| Max. SPL (1m, free field) | 138dB |
| Nominal horizontal dispersion | 60° Long Throw |
| Nominal vertical dispersion | 40° Long Throw |
| Transducers | LF: One 12" ND cone - 4" voice-coil |
| HF: One 3" aluminium diaphragm 1.4" throat compression driver | |
| Acoustic Principle | LF: Horn-loaded |
| HF: Horn-loaded | |
| Power handling AES RMS/peak | LF: 500W / 1000W |
| HF: 100W / 200W | |
| Crossover | Active / Passive - switchable |
| Nominal impedance | LF: 8 Ω |
| Nominal impedance | HF: 8 Ω |
| Connectors | Two speakON NL4 |
| Weight | 41.0 kg |
| 90 lb |
Applications.
High demand Portable sound reinforcement
Small-to-medium live music venues
Mobile DJ’s
Medium to large dance clubs
Fixed installations in concert halls, ballrooms and Houses of Worship
Related products.
TA 4D - 4 Channel FIRTEC™ DSP controlled amplifier
C WH - Single 18” Hybride Subwoofer
CPD 1214 - Powered 12” / 3” Long Throw MH loudspeaker
