C 2
“State of the art.”
C 2 Specifications.
| Specifications | C 2 unpowered |
| Frequency response | 60 - 19.000Hz ±3dB |
| LOW CUT (via DSP) | 70 / 100 / 120Hz |
| Max. SPL (1m, free field) | 134dB |
| Nominal horizontal dispersion - Rotable | 90° or 60° |
| Nominal vertical dispersion - Rotable | 60° or 90° |
| Transducers | LF: One 12" ND cone 4" voice-coil |
| HF: ne 1.75" polyester ring-diaphragm 1" throat compression driver | |
| Acoustic Principle | LF: Bass-reflex |
| HF: Rotable CD horn | |
| Power handling AES RMS/peak | 1000W / 2000W |
| Crossover | Passive 1200Hz Phase Linear Bessel |
| Nominal impedance | 8 Ω |
| Connectors | Two speakON NL4 |
| Weight | 22 kg |
| 48 lb |
Applications.
Portable sound reinforcement
Live music clubs
Mobile DJ’s
Medium scale Houses of Worship with live music
Nightclubs, Bars, Bistro
Weddings and Parties
Rehearsal Studios
