CA 4D
“4 Channel MOSFET Power Amplifier.”
CA 4D Amp modes.
SAT MODE
Another interesting solution is the SAT mode. As in a SAT system is common, the left and right signals in the woofer range are combined into one mono channel. The signal for the full-range speakers remains stereo and is amplified for the left on channel 3 and for the right on channel 4.
| • Channel 1+2 Bridge | 700Wrms / 1400Wpeak - 8 Ω | |
| 1400Wrms / 2800Wpeak - 4 Ω | ||
| • Channel 3 and 4 | 175Wrms / 350Wpeak - 8 Ω | |
| 350Wrms / 700Wpeak - 4 Ω | ||
| 700Wrms / 1400Wpeak - 2 Ω |
When using CA 4D in SAT mode, LEDs light up for channel 2 (bridge woofer) no LEDs light up for the full-range channels 3 and 4.
Applications.
Ideal for KS AUDIO unpowered active compact loudspeakers
