CB 18
“6 channel powered subwoofer.”
CB 18 Specifications.
| Specifications | CB 18 powered |
| Frequency response | 38 - 120Hz ±3dB |
| 32 - 120Hz ±6dB | |
| Max. SPL | 136dB |
| Directivity | Omni directional |
| Transducer | One long excursion 18” cone 4” voice-coil |
| Power handling AES RMS/peak | 1200W / 2400W |
| Acoustical Principal | Port-loaded |
| Amplifier | 6 PWM amplifiers - 3000Wrms |
| SAT mode: 4 Powerstages - bridge | bridge | Left | Right | |
| SESSION mode: 3 Powerstages - bridge | bridge | bridge | |
| Power Supply | SMPS (Switched Mode Power Supply) with power factor correction (PFC) |
| DSP | 32-bit, floating point, 192 kHz Sampling frequency |
| Filter Technology | IIR and FIR filters, delay adjustments, contour filters and x-over |
| Power input/output/link | powerCON in/out 110-240V 50-60Hz |
| Signal input/output/link | XLR3-F Analog/AES-EBU autoswitch |
| RJ45 Ethernet 1G T Base for KS AUDIO Remote Control | |
| Weight | 40 kg |
| 88 lb |
Applications
Sub-low amplifier/subwoofer for KS AUDIO compact systems
Portable Sound Reinforcement
Live Music Clubs
Small scale Houses of Worship with live music
Nightclubs, Bars and Restaurants
Weddings and Parties
Hotels and Casinos
Mobile DJ’s
Rehearsal Studios
