CPD 1 - HDSP™

“Small, powerful - powered.”

CPD 1 Specifications.


    Specifications
    CPD 1 powered

    Frequency response
    68 - 19.000Hz ±3dB

       LOW CUT Modes
    Off / 120Hz

    Max. SPL (1m, free field)
    134dB

    Nominal horizontal dispersion
    120° nearfield down to 60° into the farfield

    Nominal vertical dispersion
    35° with 5° down-angle

    Transducers
    LF: One 10" ND cone

    HF: One 1.75" Ring diaphragm compression driver

    Acoustic Principle
      LF: Bass-reflex

    HF: HDSP™ High Definition Sound Projector

    Power handling AES RMS/peak
      LF: 400W / 800W

      HF: 40W / 80W

    Amplifier
      Integrated, 2 powerstages: 1x PWM 1x Linear Power Stage

       Power Supply
    SMPS (Switched Mode Power Supply) with power factor correction (PFC)

       DSP
      32-bit, floating point, 192 kHz Sampling frequency

       Filter Technology
      IIR and FIR filters, delay adjustments, contour filters

    Power input
    powerCON 110-240V 50-60Hz

    Signal input
    XLR3-F and XLR3-M

    Weight
    18 kg

        40 lb
