TA 2D
“2 Channel MOSFET Power Amplifier
with digital FIRTEC™ DSP.”
TA 2D high output MOSFET power.
Two channels with lots of power make the KS AUDIO TA 2 D a very suitable amplifier to drive KS AUDIO subwoofers. The built-in FIRTEC™ DSP is easy to operate, and all KS AUDIO speakers are stored in the processor's memory.
Even with this powerful amplifier, KS AUDIO opts for the better sounding Class H solutions with 3 supply voltages.
If two channels are enough, the TA 2D is the ideal amplifier for you.
The versatile amplifier with perfect features: from a basic stereo power stage to a digitally controlled 2-way active loudspeaker system with network control and monitoring, any operating mode is possible.
However, the TA 2D finds its best application as high-performance amplifier for all KS AUDIO loudspeakers but especially subwoofers. For this purpose, the basic program is ideally matched with configurable parameters to the respective loudspeaker type. The actual set-ups are stored in the amplifiers DSP processor and can easily be loaded into the active program via the menu.
Two independent amplifier channels featuring a highly efficient 3-stage Class-H circuit provide the basic configuration of the TA 2D. Each power output stage comprises 24 fast FET transistors that guarantee superb audio performance with a frequency range of up to 50kHz.
The performance of the 2HE/19′′ amplifier with its 2×2000W is at the upper limit of the energy level that common 16A protected 230V circuits can supply. Already at 8 ohms there are 1,000W available, which is sufficient power to operate almost any loudspeaker.
The power stages are supported by a digital audio processor with high-quality 27 bit A/D converters using gain stacking technology. This allows the implementation of 2 single channels, a stereo or a 2-way system.
The signal processing programs for all KS AUDIO full-range loudspeaker systems are equipped with the FIR filter technology FIRTEC™. This means individually measured, phase-pure sound reinforcement systems with an unsurpassed sound resolution.
Modern wide-range switching power supply featuring power factor correction.
TECHNICAL EQUIPMENT
48 FET power transistors with NF-conducted triple operating voltage
Regulated switch-mode power adapter with PFC and inrush-current limiting, plus separate standby power supply, loudspeaker outputs with relay power-up delay, protective circuit against low-impedance and electrical overload.
Applications.
Ideal for all KS AUDIO unpowered subwoofers.
