VC LINE VALTEC™
“Variable Curvature Line Array.“
VC LINE VALTEC™ Specifications.
| Specifications | VC LINE VALTEC™ unpowered |
| Frequency response | 60 - 20.000Hz ±3dB |
| F MOD / D MOD low cut modes | OFF / 70 / 100 / 120Hz |
| Max. SPL (1m, free field) with TA 4D | 140dB - single element |
| Nominal horizontal dispersion | 120° |
| Nominal vertical dispersion | VALTEC™ stepless adjustable between 0° and 15° |
| Transducers | LF: Two 8” Neodymium Cone |
| HF: One 1.75" Ring diaphragm compression driver | |
| Power handling AES RMS/peak | LF: 1000W / 2000W |
| HF: 100W / 200W | |
| Acoustic principle | LF: Bass-reflex |
| HF: CPC (Constant Phase Sculpture) waveguide with VALTEC™ (Variable Acoustic Lens Technology) | |
| Nominal impedance | LF: 16 Ω |
| HF: 16 Ω | |
| Splay angle increments | 0, 1 … 15° |
| Connectors | Two speakON NL4 |
| Weight | 16,5 kg |
| 36 lb |
Very easy to create a solid and safe groundstack.
Even eassier to fly.
Applications
Small-to-medium scale theatres
Small-to-medium live music venues
Corporate AV events
Fixed installations in concert halls, ballrooms and Houses of Worship
