CPD 14
“Without consessions.”
CPD 14 Specifications.
| Specifications | CPD 14 powered |
| Frequency response | 38 - 20.000Hz ±3dB |
| LOW CUT Modes | 70 / 120Hz |
| Max. SPL (1m, free field) | 132dB - (138dB peak) |
| Nominal horizontal dispersion | 120° |
| Nominal vertical dispersion | 30° |
| Transducers | LF: Two 10" ND cone |
| Transducers | MF: Four 5" ND cone" |
| HF: one 3.5" mylar ring diaphragm 1.75" throat compression driver | |
| Acoustic Principle | LF: Bass-reflex |
| MF: Vertical array | |
| CPC (Constant Phase Sculpture) waveguide | |
| Power handling AES RMS/peak | LF: 500W / 1000W |
| MF: 250W / 500W | |
| HF: 100W / 450W | |
| Amplifier | Integrated, 4 powerstages: 3x PWM 1x MOSFET - 850Wrms |
| Power Supply | SMPS (Switched Mode Power Supply) with power factor correction (PFC) |
| 4 channel DSP | 32-bit, floating point, 192 kHz Sampling frequency |
| Filter Technology | IIR and FIR filters, delay adjustments, contour filters, time allignment |
| Power input | powerCON in/out 110-240V 50-60Hz |
| Signal input | XLR3-F and XLR3-M Analog/AES-EBU autoswitch |
| RJ45 Ethernet 1G T Base for Dante™ and KS AUDIO REMOTE Control | |
| - Dante™ optional! - | |
| Weight | 27.0 kg |
| 59.4 lb | |
| Specs for model from 2021 |
Applications.
When only the best is good enough
All scale theatres and opera houses
Small live music venues
Corporate AV events
Fixed installations in concert halls, ballrooms and Houses of Worship
Media & board rooms
Trade shows
