TA 4D
“4 Channel MOSFET Power Amplifier.”
TA 4D Amp modes.
3-WAY MODE
KS Beschallungstechnik also develops systems for third parties. These systems are usually 3-way line arrays. For KS AUDIO, this only applies to the U LINE.
| • Woofer Bridge | 2000Wrms / 4000Wpeak - 8 Ω | |
| Chanel 1+2 | one U LINE | |
| 2500Wrms / 5000Wpeak - 4 Ω | ||
| two U LINE | ||
| • Channel 3 - Mid-range | 500Wrms / 1000Wpeak - 8 Ω | |
| one U LINE | ||
| 1000Wrms / 2000Wpeak - 4 Ω | ||
| two U LINE | ||
| • Channel 4 - High-range | 500Wrms / 1000Wpeak - 8 Ω | |
| one U LINE | ||
| 1000Wrms / 2000Wpeak - 4 Ω | ||
| two U LINE |
As with the normal TRI-AMP mode, in this application the "bridge" LED of channel 2 lights up for both woofer channels 1 + 2 and the "Bi-amp" LED of channel 3 lights up for channels 3 + 4 for the mid and high range.
Applications.
All KS AUDIO unpowered loudspeakers
