TA 4D
“4 Channel MOSFET Power Amplifier.”
TA 4D Amp modes.
SAT MODE
Another interesting solution is the SAT mode. As in a SAT system is common, the left and right signals in the woofer range are combined into one mono channel. The signal for the full-range speakers remains stereo and is amplified for the left on channel 3 and for the right on channel 4.
| • Channel 1+2 Bridge | 2000Wrms / 4000Wpeak - 8 Ω | |
| 2500Wrms / 5000Wpeak - 4 Ω | ||
| • Channel 3 and 4 | 500Wrms / 1000Wpeak - 8 Ω | |
| 1000Wrms / 2000Wpeak - 4 Ω |
When using TA 4D in SAT mode, LEDs light up for channel 2 (bridge woofer) no LEDs light up for the full-range channels 3 and 4.
Applications.
All KS AUDIO unpowered loudspeakers
