T SUB
“Extended Lows.”
T SUB specifications.
| Specifications | T SUB unpowered |
| Frequency response | 35 - 120Hz ±3dB |
| 30 - 120Hz ±6dB | |
| F MOD / D MOD hi-cut modes | 70Hz / 100Hz / 120Hz |
| Max. SPL | 144dB |
| Nominal impedance | 4 Ω |
| Directivity | Omni directional |
| Transducers | Eight (!) 10” Cone 3" Voice-coil, 30mm Excursion Cone |
| Power handling AES RMS/peak | 4000W / 8000W |
| Acoustical Principal | Band-pass | Push-pull |
| Connectors | speakON NL4 in/out |
| Weight | 131 kg |
| 289 lb |
Applications
Large-scale touring sound reinforcement for outdoor festivals, stadia, arenas and concert halls
Premium fixed installations in concert halls, theatres and sports arenas
