S LINE

“Ultra Compact Line Array.”

S LINE Amplification.

TA 4D - 4 channel system amplifier

We recommend driving up to 8 elements with a TA 4D system amplifier. Better sonic performance is achieved with fewer elements, allowing more accurate processing. — We recommend driving up to 8 elements with a **TA 4D** system amplifier. Better sonic performance is achieved with fewer elements, allowing more accurate processing.

CA 4D - 4 channel system amplifier

If the maximum power of S LINE is not required but there is a preference for more accuracy, we recommend replacing the TA 4D with two CA 4D or adding a CA 4D to a TA 4D. With more amplifier channels, more precise, more individual processing of the d… — If the maximum power of **S LINE** is not required but there is a preference for more accuracy, we recommend replacing the **TA 4D** with two **CA 4D** or adding a **CA 4D** to a **TA 4D**. With more amplifier channels, more precise, more individual processing of the differently curved line array elements is possible.

Channel distribution


    Channel 1
    LF: Element 1

    LF: Element 2 (optional)

    LF: Element 3 (optional)

    LF: Element 4 (optional)

    Channel 2
    HF: Element 1

    HF: Element 2  (optional)

    HF: Element 3  (optional)

    HF: Element 4  (optional)

    Channel 3
    LF: Element 5

    LF: Element 6 (optional)

    LF: Element 7 (optional)

    LF: Element 8 (optional)

    Channel 4
    HF: Element 5

    HF: Element 6 (optional)

    HF: Element 7 (optional)

    HF: Element 8 (optional)
