S LINE

“Ultra Compact Line Array.”

S LINE Compact & Versatile.


    Specifications
    S LINE unpowered

    Frequency response
    70 - 20.000Hz ±3dB

    F MOD / D MOD low cut modes
    OFF / 70 / 100 / 120Hz

    Max. SPL (1m, free field) with TA 4D
    123dB - single element

    Nominal horizontal dispersion (used as line array)
    100° - 5° a-symmetrical

    Nominal vertical dispersion (used as line-array)
    20° Wide version

    7° Narrow version

    Transducers
    LF: Two 6” Neodymium Cone

    HF: One 1.75" Ring diaphragm compression driver

    Power handling AES RMS/peak
      LF: 200W / 400W

    HF: 80W / 160W

    Acoustic Principle
      LF: Bass-reflex

    HF: Asymm. Cylindrical Linedriver

    Nominal impedance
      LF: 16 Ω

    HF: 16 Ω

    Connectors
    Two speakON NL4

    Weight
    14 kg

        31 lb
